Description
Seco
1 Lot of 10 Inserts
MSRP: $100.00
- Insert Style: WNMG
- Insert Shape Code: W
- Insert Size Code: 333
- Insert Shape: Trigon
- Clearance Code: N
- Tolerance Code: M
- Insert Material: Solid Carbide
- Manufacturer Grade: TP2501
- Hole Diameter (Mm) ( – 0 Decimals): 3.81
- Hole Diameter (Decimal Inch): 0.1500
- Inscribed Circle (Inch): 3/8
- Inscribed Circle (Decimal Inch): 0.3750
- Insert Holding Method: Pin; Clamp
- Insert Hand: Neutral
- Insert Thickness (Inch): 3/16
- Insert Thickness (Decimal Inch): 0.1875
- Corner Radius (Inch): 3/64
- Corner Radius (Decimal Inch): 0.0469
- Included Angle: 80.0
- Relief Angle: 0
- Coating Process: Duratomic
- Rake: Negative
- Primary Workpiece Material: P
- Secondary Workpiece Material: K
- Cutting Direction: Neutral
- Single or Multi Tipped: Multi Tipped
- Chip Breaker: G
- Coating/Finish: Al2O3
These items are new and in great condition. SOLD AS IS.
Please review photos, comes as shown.
Fast shipping, straight from our warehouse in sunny Florida!
Industry Recycles
155 Center Ct, Venice, FL 34285
January 03 2023
TB 12357
Cab Stu Bin 4
BRAND: SECO
MSRP: $100.00
INSERT MATERIAL: Carbide
MODEL: 02960713
MPN: Does Not Apply
INSERT TYPE: Turning Insert
COUNTRY/REGION OF MANUFACTURE: Sweden
