Description
Sphinx
1 Lot of 10 Micro Drill Bits
MSRP: $100.00
- Drill Bit Size (Decimal Inch) 0.0142
- Tool Material Solid Carbide
- Flute Length (Decimal Inch) 0.0950
- Coating/Finish Bright/Uncoated
- Coolant Through No
- Drill Point Angle 118
- Cutting Direction Right Hand
- Maximum Drilling Depth (mm) 2.40
- Series 50 699
- Overall Length (Decimal Inch) 0.984
- Flute Type Spiral
- Shank Type Straight-Cylindrical
- Point Type Four Facet
- Tool Application Through Hole Drilling; Blind Hole
- Web Thinning Web-Thinned
- Web Configuration Tapered
- Drill Bit Diameter Tolerance +0.000 to -0.004 mm
- Primary Workpiece Material Cast Iron; Steel
- Primary Workpiece Material Code P; K
- Secondary Workpiece Material Non-Ferrous Metal; Stainless Steel
- Secondary Workpiece Material Code M; N
- Standards DIN 1899A
- Shank Diameter (mm) 1.00
- Flute By Diameter Ratio 6xD
- Material Grade K20/30
- Spiral Type Regular
- UNSPSC Code 23241600
These items are new and in good condition. SOLD AS IS.
Please review photos, comes as shown.
Fast shipping, straight from our warehouse in sunny Florida!
Industry Recycles
155 Center Ct, Venice, FL 34285
March 06 2024
TB 15967
BW 2 Bin 31
BRAND: Sphinx
MSRP: $100.00
MODEL: 40.50699.0036
MPN: Does Not Apply
COUNTRY/REGION OF MANUFACTURE: Unknown
LOCATION: TB15967BW2Bin31
