Description
Sandvik Coromant
Carbide Milling Inserts
MSRP: $450
- Insert Style RCHT
- Insert Size 19
- Insert Material Solid Carbide
- Insert Shape Round
- Manufacturer Grade 2040
- Corner Radius (Decimal Inch) 0.3750
- Corner Radius (mm) 9.53
- Number Of Cutting Edges 8
- Thickness (Decimal Inch – 4 Decimals) 0.2500
- Thickness (mm) 6.35
- Coating/Finish TiN; TiCrN; Al2O3
- Relief Angle 7.00
- Insert Size Code 190600
- Material Grade P45; S30; M40
- Width (Inch) 3/4
- Length (Inch) 3/4
- Thickness (Inch) 1/4
- Inscribed Circle (Inch) 3/4
- Inscribed Circle (Decimal Inch) 0.7500
- Inscribed Circle (mm) 19.05
- Thickness Range (Decimal Inch) 0.2500 to 0.3500
- Corner Radius (Inch) 3/8
- Inscribed Circle Range (Decimal Inch) 0.7000 to 1.0000
- Length Range (Decimal Inch) 0.7000 to 0.9000
- Insert Hand Neutral
- Maximum Depth of Cut (Decimal Inch) 0.1098
- Maximum Depth of Cut (mm) 2.79
- Series RCHT
- Coating Process CVD
- Hole Diameter (Mm) ( – 0 Decimals) 0.26
- Hole Diameter (Decimal Inch) 0.2559
- Rake Positive
- Primary Workpiece Material Stainless Steel; Superalloys & Titanium; Steel
- Primary Workpiece Material Code P; S; M
- Ansi Code RCHT 19 06 00-ML 2040
- Iso Code RCHT 19 06 00-ML 2040
- Standards ISO; ANSI
- Convex Radius (Decimal Inch) 0.3750
- Cutting Edge Style Rounded
- Manufacturers Catalog Number RCHT 19 06 00-ML 2040
- Cutter Series Compatibility RA200
- Chip Breaker ML
- UNSPSC Code 23291601
- Material Application Stainless Steel; Superalloys & Titanium; Steel
- Insert Holding Method Screw
- Coating Classification CVD
- Single or Double Sided Insert Single
- Included Angle Degree 360
- Width (Decimal Inch – 4 Decimals) 0.7500
- Multi-Use Tool Yes
- Length (Decimal Inch – 4 Decimals) 0.7500
*NEW-OPEN BOX. Item is in excellent condition, with no signs of previous use or wear. Open package for inspection and photos only. WARRANTY NOT INCLUDED. SOLD AS IS.
Please review photos, comes as shown.
Fast shipping, straight from our warehouse in sunny Florida!
Industry Recycles
155 Center Ct, Venice, FL 34285
February 12 2025
VM13890
Cab May Bin 6
BRAND: Sandvik Coromant
MSRP: $450
INSERT MATERIAL: Carbide
INSERT TYPE: Milling Insert
COUNTRY/REGION OF MANUFACTURE: Sweden
LOCATION: VM13890CabMayBin6
