Description
Hertel
Turning Insert
MSRP: $30.00
- Insert Style DCMX
- ISO Size Code 11T308
- ANSI Size Code 32.52
- Insert Shape D – Diamond (Rhombic) 55-Deg
- Inscribed Circle (Decimal Inch) 0.3750
- Inscribed Circle (Inch) 3/8
- Corner Radius (Inch) 1/32
- Corner Radius (Decimal Inch) 0.0313
- Insert Material PCD
- Manufacturer Grade HT420CD
- Coating/Finish Bright/Uncoated
- Insert Thickness (Decimal Inch) 0.1560
- Insert Thickness (Inch) 5/32
- Grade Characteristics Hardened Materials (H) – High Wear-Resistance
- Side Clearance Negative
- Insert Shape Code D
- Hole Diameter (Decimal Inch) 0.2030
- ISO Insert Code DCMX11T308
- ANSI Insert Code DCMX32.52
- Insert Holding Method Screw
- Clearance Code C
- Tolerance Code M
- Primary Workpiece Material Code H
- Material Grade C2
- Chip Breaker X
- UNSPSC Code 23242105
- Insert Size Code 32.52
This item appears to be new and in good condition. SOLD AS IS.
Please review photos, comes as shown.
Fast shipping, straight from our warehouse in sunny Florida!
Industry Recycles
155 Center Ct, Venice, FL 34285
May 13 2025
TB 19567
BW 3 Bin 21
BRAND: Hertel
MSRP: $30.00
UNIT TYPE: Unit
INSERT MATERIAL: N/A
MODEL: 44879690
MPN: Does Not Apply
INSERT TYPE: Turning Insert
COUNTRY/REGION OF MANUFACTURE: Unknown
UNIT QUANTITY: N/A
CALIFORNIA PROP 65 WARNING: N/A
LOCATION: TB19567BW3Bin21
