Erickson Collet Chuck: 2.03 To 20 Mm Capacity, Er Collet, Taper Shank 1261619

Erickson
Collet Chuck

MSRP: $125.00

• Collet System ER
• Collet Series ER32
• Shank Type Taper
• Taper Size CAT40
• Projection (Decimal Inch) 2.7500
• Projection (Inch) 2-3/4
• Through Coolant Yes
• Minimum Collet Capacity (mm) 2.03
• Minimum Collet Capacity (Decimal Inch) 0.0800
• Maximum Collet Capacity (mm) 20.00
• Maximum Collet Capacity (Decimal Inch) 0.7874
• Overall Length (Decimal Inch) 5.4370
• Actuator Type Wrench
• Nose Diameter (Decimal Inch – 4 Decimals) 1.9700
• Coolant Type Through-Spindle & DIN Flange
• Collet Nut Diameter (mm) 50.01
• Collet Nut Diameter (Decimal Inch) 1.9690
• Product Service Code 5136
• Balanced To Rpm 12000

This item appears to be new and in great condition. SOLD AS IS.

Please review photos, comes as shown.
