De-Sta-Co Manual Hold-Down Toggle Clamp: Horizontal Flanged Base 5310

DE-STA-CO Manual Hold-Down Toggle Clamp: Horizontal Flanged Base 5310

MSRP: $80

• Handle Orientation Horizontal
• Bar Style Solid
• Base Style Flanged
• Bar End Type Closed
• Holding Capacity (N) 5780.00
• Holding Capacity (Lb.) 1299.40
• Length Distance Between Mount Holes (mm) 92.20
• Length Distance Between Mount Holes 3.63 in; 92.2 mm
• Length Distance Between Mount Holes (Inch) 3.63
• Height Under Bar (Decimal Inch) 1.3100
• Height Under Bar (mm) 33.27
• Overall Length (mm) 282.70
• Overall Length (Decimal Inch) 11.1300
• Overall Height (Decimal Inch) 2.0000
• Overall Height (Mm – 5 Decimals) 50.80
• Base Length (mm) 117.60
• Base Width (Inch) 1.5000
• Base Width 38.10
• Handle Style Straight
• Material Forged Alloy Steel
• Handle Material Forged Alloy Steel
• Handle Color Red
• Bar Opening (Degrees) 90
• Handle Movement (Degrees) 69
• Bar Width (Inch) 3/4
• Bar Width (mm) 19.05
• Bar Width (Decimal Inch) 0.7500
• Bar Thickness (mm) 20.07
• UNSPSC Code 31162902
• Bar Thickness (Decimal Inch) 0.7900
• Front Of Base To Toggle Tip 2.63 in
• Front of Base To Tip Of Toggle Bar (Decimal Inch) 2.6300
• Front of Base To Tip Of Toggle Bar (mm) 66.80
• Finish Coating Oxide
• Country of Origin Thailand
• Ordered as Part # 5310

Secure your workpieces with the DE-STA-CO Manual Hold-Down Toggle Clamp, designed for reliable and efficient clamping. Model 5310 features a horizontal flanged base, ideal for those needing a stable and sturdy attachment option. The clamp is crafted with the quality and durability that the DESTACO brand is known for, ensuring your projects are held securely during operation. This unit is manufactured in Thailand and adheres to the California Prop 65 warning standards. Please review the description thoroughly for specifics on the clamp type, arm configuration, and unit quantity, as depicted in the ‘see description’ placeholders. By doing so, you’ll have all the necessary information to effectively utilize this toggle clamp in your workshop.

Please review photos, comes as shown.
