Walter Solid Carbide Jobber Drill 16.7mm 140° Point 5924933
Walter Solid Carbide Jobber Drill 16.7mm 140° Point 5924933
Regular price
$156.64 USD
Regular price
$320.00 USD
Sale price
$156.64 USD
Walter
MSRP: $320.00
Model: 5924933
Description:
Drill Bit Size (mm) : 16.70
Drill Bit Size (Decimal Inch) : 0.6575
Drill Point Angle: 140
Drill Bit Material: Solid Carbide
Drill Bit Finish/Coating: AlCrN
Flute Type: Spiral
Cutting Direction: Right Hand
Shank Type: Straight
Coolant Through: Coolant Through
Flute Length (mm): 93.00
Flute Length (Decimal Inch): 3.6614
Overall Length (mm): 143.00
Overall Length (Decimal Inch): 5.6299
Flute Length x Diameter Ratio: 5xD
Point Type: X-treme
Shank Diameter (mm): 18.00
Shank Diameter (Decimal Inch): 0.7087
Maximum Drilling Depth (Decimal Inch): 2.7953
Maximum Drilling Depth (mm): 71.00
Spiral Type: Regular Spiral
Shank Length (mm): 48.00
Shank Length (Decimal Inch): 1.8898
Specification Designation: DIN
Web Configuration: Tapered
Drill Bit Diameter Tolerance (mm): m7
Number of Flutes: 2
Web Thinning: Web-Thinned
Specification Number: DIN 6535HA; DIN 6537L
Material Grade: K30F
Series/List: A3399XPL
This listing is for One Solid Carbide Jobber Drill that is in the picture as well as described. Please ask any questions prior to buying!
Florida customer's are required to pay a 7% sales tax.
Tina July 13 2020
TB 5703
BW 3 Bin 27
