Supermill Carbide Corner Radius End Mill 3/4" X 2-1/4" X 5" 4FL XPVS750L-030

Supermill
Carbide Corner Radius End Mill

MSRP: $400

• Mill Diameter (Inch) 3/4
• Mill Diameter (Decimal Inch) 0.7500
• Number Of Flutes 4
• Length of Cut (Inch) 2-1/4
• Single Or Double End Single
• End Mill Material Solid Carbide
• Coating/Finish AlCrN
• Overall Length (Inch) 5
• Centercutting Yes
• Flute Direction Right Hand
• Corner Radius (Decimal Inch) 0.0300
• Variable Index Yes
• Variable Helix Yes
• Cutting Direction Right Hand
• Coolant Through No
• Pitch Normal
• Overall Length (Decimal Inch) 5.0000
• Chipbreaker No
• End Type Corner Radius
• Length Of Cut (Decimal Inch - 4 Decimals) 2.2500
• Length Type Standard
• Flute Type Spiral
• Extended Reach No
• Shank Type Straight-Cylindrical
• Material Removal Type Roughing & Finishing
• Shank Diameter (Decimal Inch) 0.7500
• Shank Diameter (Inch) 3/4
• Primary Workpiece Material Stainless Steel; Cast Iron; Steel
• UNSPSC Code 27112803
• Primary Workpiece Material Code P; K; M
• Material Grade Micrograin
• Series XPVS
• Material Application Stainless Steel; Cast Iron; Steel
• Coating Classification PVD
• For Use With. Toolholders

*Open package for inspection & photos only*

Please review photos, comes as shown.
