Superbee Carbide Milling Inserts EM19160 Grade ET520 Qty. 10 #EM19160ET520

Superbee Carbide Milling Inserts EM19160 Grade ET520 Qty. 10 #EM19160ET520

MSRP: $285

• Insert Style EM
• Insert Size 19
• Insert Material Solid Carbide
• Insert Shape Parallelogram
• Manufacturer Grade ET520
• Number Of Cutting Edges 2
• Thickness (Decimal Inch - 4 Decimals) 0.1560
• Thickness (mm) 3.96
• Coating/Finish AlTiN
• Insert Size Code 19160
• Material Grade C5
• Width (Inch) 1/2
• Length (Inch) 3/4
• Thickness (Inch) 5/32
• Inscribed Circle (Inch) 1/2
• Inscribed Circle (Decimal Inch) 0.5000
• Inscribed Circle (mm) 12.70
• Thickness Range (Decimal Inch) 0.1500 to 0.1750
• Length Range (Decimal Inch) 0.7000 to 0.9000
• Insert Hand Right Hand
• Series EM
• Coating Process PVD
• Rake Positive
• Primary Workpiece Material Stainless Steel; Steel
• Primary Workpiece Material Code P; M
• Ansi Code EM19160ET520
• Convex Radius (Decimal Inch) 0.1600
• Cutting Edge Style Honed
• Manufacturers Catalog Number EM19160
• Cutter Series Compatibility BB; BC; BD; BE; BBD; CMS; CM; CB
• Chip Breaker None
• Material Application Stainless Steel; Steel
• UNSPSC Code 23291601
• Insert Holding Method Screw
• Coating Classification PVD
• Single or Double Sided Insert Double
• Length (mm) 19.05
• Width (Decimal Inch - 4 Decimals) 0.5000
• Width (mm - 2 Decimals) 12.70
• Multi-Use Tool Yes
• Length (Decimal Inch - 4 Decimals) 0.7500
• System Of Measurement Metric

(Description).

Please review photos, comes as shown.
