SUMITOMO SC Screw Machine Length Drill Bit: 0.111″ Dia, 135 ° U101012

Sumitomo
Solid Carbide Screw Machine Length Drill Bit

MSRP: $52.00

• Drill Bit Size (Decimal Inch) 0.1110
• Drill Bit Size (mm) 2.82
• Tool Material Solid Carbide
• Coating/Finish Coated
• Drill Point Angle 135
• Coolant Through No
• Shank Type Straight-Cylindrical
• Number Of Flutes 2
• Shank Diameter (Decimal Inch) 0.1250
• Overall Length (Decimal Inch) 1.7717
• Series MDW-GS
• Web Configuration Tapered
• Drill Length Type Screw Machine
• Maximum Drilling Depth (Decimal Inch) 0.3453
• Maximum Drilling Depth (mm) 8.77
• Shank Length (Decimal Inch) 1.1811
• Drill Point Length (mm) 0.58
• Drill Point Length (Decimal Inch) 0.0228
• Flute By Diameter Ratio 2xD
• Drill Bit Diameter Tolerance h8
• Flute Length (Decimal Inch) 0.5118
• Drill Bit Size Range (Decimal Inch) 0.1000 to 0.1500
• Drill Bit Size Range (mm) 0.00 to 3.50

This item is new and in great condition. SOLD AS IS.

Please review photos, comes as shown.

Fast shipping, straight from our warehouse in sunny Florida!
