Sumitomo Carbide Turning Inserts Neutral SNMG544EMU AC8025P QTY 10 19P7ALK

Sumitomo
1 Pack of 10 Carbide Turning Inserts

MSRP: $190

• Relief Angle 0

• Corner Radius (Inch) 1/16
• Corner Radius (Decimal Inch) 0.0625
• Included Angle 90
• Manufacturer Grade AC8025P
• Coating/Finish Absotech
• Insert Hand Neutral
• Insert Thickness (Inch) 1/4
• Insert Thickness (Decimal Inch) 0.2500
• Series SN
• Inscribed Circle (Inch) 5/8
• Inscribed Circle (Decimal Inch) 0.6250
• Insert Material Carbide
• Insert Shape Square
• Insert Shape Code S
• Hole Diameter (Decimal Inch) 0.2500
• Insert Holding Method Pin; Clamp
• Width (Inch) 5/8
• Clearance Code N
• Tolerance Code M
• Coating Process CVD
• Rake Negative
• Insert Length (Decimal Inch) 0.6250
• Insert Length (Inch) 5/8
• Primary Workpiece Material Steel
• Primary Workpiece Material Code P
• Iso Code SNMG150616N-MU
• Standards ISO 13399; ANSI
• Chip Breaker EMU
• Width (Decimal Inch - 4 Decimals) 0.6250
• Multi-Use Tool No
• Full Radius No
• UNSPSC Code 23242105
• Insert Style SNMG
• Insert Size Code 544

Please review photos, comes as shown.
