SUMITOMO 2NCCCGA21.52 BNC500 PCBN Turning Inserts qty2 16JZDHX

SUMITOMO

 2NCCCGA21.52 BNC500 PCBN Turning Inserts qty2 16JZDHX
MSRP: $120

• Insert Style 2NC-CCGA
• Insert Shape Code C
• Insert Size Code 21.52
• Insert Shape Diamond
• Coating/Finish TiC
• Corner Radius (Inch) 1/32
• Corner Radius (Decimal Inch) 0.0312
• Insert Material Polycrystalline Cubic Boron Nitride
• Hole Diameter (Decimal Inch) 0.1102
• Inscribed Circle (Inch) 1/4
• Inscribed Circle (Decimal Inch) 0.2500
• Insert Holding Method Screw
• Insert Thickness (Inch) 3/32
• Insert Thickness (Decimal Inch) 0.0937
• Clearance Code C
• Tolerance Code G
• Manufacturer Grade BNC500
• Included Angle 80.0
• Relief Angle 7
• Series C
• Coating Process PVD
• Rake Positive
• Insert Length (Decimal Inch) 0.0906
• Number Of Cutting Edges 2
• Primary Workpiece Material Cast Iron
• Primary Workpiece Material Code K
• Ansi Code 2NCCCGA21.52
• Iso Code 2NC-CCGW060208
• Standards ISO 13399
• Chip Breaker A

 Please review photos, comes as shown.
