SGS Carbide Jobber Drill Letter T RH 0.3580" D x 2-3/4" x 4-1/4"

SGS Carbide Jobber Drill Letter T RH 0.3580" D x 2-3/4" x 4-1/4"

$52.90 USD
$115.00 USD $52.90 USD
Sale Sold out
Shipping calculated at checkout.

SGS Carbide Jobber Drill Letter T RH 0.3580" D x 2-3/4" x 4-1/4"

Item Description
SGS

MSRP: $115

Model: 53220

Description:

Drill Bit Size (Letter) T
Drill Bit Size (Decimal Inch) 0.3580
Drill Point Angle 150
Drill Bit Material Solid Carbide
Drill Bit Finish/Coating Bright
Flute Type Spiral
Cutting Direction Right Hand
Shank Type Straight
Coolant Through No
Flute Length (Inch) 2-3/4
Flute Length (Decimal Inch) 2.7500
Overall Length (Decimal Inch) 4.2500
Overall Length (Inch) 4-1/4
Flute Length x Diameter Ratio 5xD
Point Type Standard
Shank Diameter (Decimal Inch) 0.3580
Maximum Drilling Depth (Decimal Inch) 2.2031
Maximum Drilling Depth (Inch) 2-13/64
Spiral Type Regular Spiral
Shank Length (Inch) 1-1/2
Shank Length (Decimal Inch) 1.5000
Web Configuration Tapered
Drill Bit Diameter Tolerance (Decimal Inch) +0.0000 to -0.0005
Number of Flutes 3
Web Thinning Web-Thinned
Drill Bit Grade General Purpose
Material Grade Micrograin
Series/List 103



This listing is for One Carbide Jobber Drill that is in the picture as well as described. Comes exactly as shown in photos. Please ask any questions prior to buying!
