SECO Slotting Milling Tip Insert MM10-10.50-HF-MD08 F15M, Carbide Qty 2 02424996

Seco
1 Lot of 2 Slotting Milling Tip Inserts

MSRP: $150.00

• Milling Tip Type Slotting
• Milling Tip Style MM10
• Maximum Depth of Cut (Decimal Inch) 0.0170
• Cutting Diameter (Decimal Inch) 0.1970
• Tool Material Carbide
• Manufacturer Grade F15M
• Insert Hand Right Hand
• Chipbreaker MD08
• Series MM10
• Coating Process PVD
• Corner Radius (Decimal Inch) 0.0310
• Corner Radius (Inch) 1/32
• Cutting Width (Decimal Inch) 0.394
• Functional Length (Decimal Inch) 0.3350
• Primary Workpiece Material Hard Material
• Primary Workpiece Material Code H
• Standards ANSI
• Milling Tip Full Description MM10-10.50-HF-MD08
• Lead Angle 90
• Manufacturers Catalog Number 02424996
• Chamfer Angle 0
• Overall Length (Decimal Inch) 0.335
• Insert Size 10.50-HF
• Coolant Through No
• Material Grade H10
• Included Angle Degree 90
• Coating/Finish TiN; TiAlN
• UNSPSC Code 23291601
• Length Of Cut (Decimal Inch - 4 Decimals) 0.0170
• Number Of Flutes 2
• Extension From Holder (Inch) 0.3350

These items appear to be new and in good condition. SOLD AS IS.

Please review photos, comes as shown.

Fast shipping, straight from our warehouse in sunny Florida!
