SECO Screw Machine Length Drill Bit: 17/64″ Dia, 140 ° Point 02691564

SECO

 Screw Machine Length Drill Bit: 17/64″ Dia, 140 ° Point 02691564
MSRP: $150

•

• Drill Bit Size (Inch) 17/64
• Tool Material Solid Carbide
• Cutting Direction Right Hand
• Coating/Finish Coated
• Number Of Flutes 2
• Spiral Type Regular
• Flute Type Spiral
• Drill Point Angle 140
• Coolant Through Yes
• Shank Type Straight-Cylindrical
• Shank Diameter (Decimal Inch) 0.3150
• Overall Length (Decimal Inch) 3.1100
• Series SD203A
• Web Thinning Web-Thinned
• Drill Length Type Screw Machine
• Maximum Drilling Depth (Decimal Inch) 0.9800
• Shank Length (Decimal Inch) 1.4170
• Drill Point Length (mm) 1.20
• Flute By Diameter Ratio 3xD
• Tool Performance High Performance
• Drill Bit Diameter Tolerance m7
• Standards DIN
• Flute Length (Decimal Inch) 1.3380
• Drill Bit Size Range (Decimal Inch) 0.2500 to 0.3000
• UNSPSC Code 23241635

Please review photos, comes as shown.
