Sandvik Coromant Jobber Length Drill Bit 8.70 mm (0.3425) Dia 147 deg 6040563

Sandvik Coromant
Jobber Length Drill Bit

MSRP: $400.00

• Drill Bit Size (mm) 8.70
• Drill Bit Size (Decimal Inch) 0.3425
• Drill Bit Material Solid Carbide
• Drill Point Angle (Degrees) 147
• Coating/Finish Multi-layer
• Flute Type Regular Spiral
• Cutting Direction Right Hand
• Point Type Standard
• Primary Workpiece Material Steel
• Specification Number DIN 6535HA
• Coolant Through Yes
• Number of Flutes 2
• Flute Length (mm) 95.00
• Flute Length (Decimal Inch) 3.7402
• Primary Workpiece Material Code P
• Shank Diameter (Decimal Inch) 0.3937
• Overall Length (mm) 139.00
• Spiral Type Regular
• Overall Length (Decimal Inch) 5.4724
• Proprietary Coating/Finish PVD TiAlSiN+TiSiN
• Series 860-PM
• Tool Application Drilling
• Flute By Diameter Ratio 10xD
• Shank Diameter (mm) 10
• Maximum Drilling Depth (Decimal Inch) 3.7402
• Shank Length (Decimal Inch) 1.7322
• Number of Flats 0
• Drill Point Length (Decimal Inch) 0.0551
• Drill Bit Diameter Tolerance m7
• Shank Type Straight
• Tool Performance High Performance
• Double Margin No
• Drill Bit Grade Specialized
• Drill Bit Size Range (Decimal Inch) 0.3000 - 0.3500
• Drill Bit Size Range (mm) 8.00 - 9.00
• Material Grade 4234
• Specification Designation DIN

(Description).

Please review photos, comes as shown.
