SANDVIK COROMANT 490R08T312MPM 4220 Carbide Milling Insert Qty 10 5762301

Sandvik Coromant
1 Lot of 10 Inserts

MSRP: $150.00

• Insert Style 490R
• Insert Size 08T312
• Insert Material Solid Carbide
• Manufacturer Grade 4220
• Inscribed Circle (Decimal Inch) 0.3150
• Inscribed Circle (mm) 8.00
• Thickness Range (Decimal Inch) 0.1250 to 0.1500
• Corner Radius (Decimal Inch) 0.0472
• Corner Radius (mm) 1.20
• Inscribed Circle Range (Decimal Inch) 0.3000 to 0.3500
• Insert Hand Right Hand
• Relief Angle 15.00
• Coating Process MTCVD
• Hole Diameter (Mm) ( - 0 Decimals) 2.80
• Hole Diameter (Decimal Inch) 0.1102
• Maximum Depth of Cut (Decimal Inch) 0.2165
• Maximum Depth of Cut (mm) 5.50
• Iso Code 490R-08T312M-PM 4220
• Cutting Edge Style ER Treated
• Manufacturers Catalog Number 5762301
• Chip Breaker PM
• Shape Square
• Thickness (mm) 3.30
• Coating/Finish TiCN; TiN; Al2O3
• Included Angle Degree 90
• Thickness (Decimal Inch - 4 Decimals) 0.1299

These items are new and in original sealed package. SOLD AS IS.

Please review photos, comes as shown.
