Sandvik 1P220-0476-XA 1630 CoroMill Plura carbide end mill for heavy roughing
Sandvik 1P220-0476-XA 1630 CoroMill Plura carbide end mill for heavy roughing
Regular price
$72.17 USD
Regular price
$153.00 USD
Sale price
$72.17 USD
Shipping calculated at checkout.
Couldn't load pickup availability
BRAND Sandvik
Item
MSRP: $
- specs
Cutting diameter (DC)
4.763 mm
Lower cutting diameter tolerance(DCTOLL)
-0.04 mm
Upper cutting diameter tolerance(DCTOLU)
-0.025 mm
Tool cutting edge angle (KAPR)
90 deg
Cutting diameter face contact(DCF)
4.509 mm
Corner chamfer(KCH)
45 deg
Corner chamfer width(CHW)
0.127 mm
Depth of cut maximum (APMX)
6.35 mm
Depth of cut maximum(APMXFFW)
6.35 mm
Depth of cut maximum(APMXPFW)
6.35 mm
Center cutting capability(CCC)
Yes
Usable length (LU)
6.35 mm
Peripheral effective cutting edge count(ZEFP)
2
Maximum ramping angle (RMPX)
5 deg
Connection - machine side(ADINTMS)
Cylindrical shank without clamping features -inch: 3/16
Connection diameter tolerance(TCDCON)
h6
Grade (GRADE)
1630
Substrate(SUBSTRATE)
HW
(Description).
Please review photos, comes as shown.
Fast shipping, straight from our warehouse in sunny Florida!
