Precision Shoulder Screw: 1/8″ Shoulder Dia Qty 10 SCB250-4140-7

1 Lot of 10 Precision Shoulder Screws


MSRP: $60.00

• Product Type Precision Shoulder Screw
• Drive Size 5/64 in
• Drive Type Hex Socket
• Shoulder Diameter (Inch) 1/8
• Shoulder Diameter (Decimal Inch) 0.1250
• Shoulder Diameter (mm) 3.18
• Head Type Rounded
• Shoulder Length (Inch) 1/2
• Shoulder Length (mm) 12.70
• Material Grade 4140
• Thread Size #4-40
• Finish Black Oxide
• Thread Fit Class 2A
• Thread Length (Decimal Inch) 0.1560
• Material Alloy Steel
• Standards REACH; PROP 65; AISI 4140; WEEE; Mil-C- 13924A, Class 3; RoHS Compliant; DFARS
• Head Height (Inch) 1/8
• Head Height (Decimal Inch) 0.1250
• Thread Standard UNC
• Overall Length (Inch) 25/32
• Overall Length (Decimal Inch) 0.7813
• Head Diameter (Inch) 1/4
• Head Diameter (Decimal Inch) 0.2500
• UNSPSC Code 31161619

These items are new and in the original package. SOLD AS IS.

Please review photos, comes as shown.

Fast shipping, straight from our warehouse in sunny Florida!
