Drill Bit Size: 9/16"

Drill Bit Size: 0.5469

Drill Point Angle: 150

Drill Bit Material: Solid Carbide

Drill Bit Finish/Coating: Bright

Flute Type: Spiral

Cutting Direction: Right Hand

Shank Type: Straight

Coolant Through: NonCoolant Through

Flute Length (Inch): 2-19/32

Flute Length (Decimal Inch): 2.5938

Overall Length (Decimal Inch): 4.2188

Overall Length (Inch): 4-7/32

Point Type: Notched

Shank Diameter (Inch): 35/64

Maximum Drilling Depth (Decimal Inch): 1.6410

Spiral Type: Regular Spiral

Specification Designation: DIN

Web Configuration: Tapered

Number of Flutes: 3

Web Thinning: Web-Thinned

Specification Number: DIN 1897

Series/List: 270

Through Coolant: No
