Item Number
83010103
Catalogue No.
STMT1-50K150V-1P
Short Description
SPD Type 1, 50kA, Uc150V, L-N, 1 Pole, 2 Modules, Monobloc
EAN/UPC Code
8435297852322
ROHS Compliant
Yes
IEC SPD Type
Type 1 / Class I
Nominal Operating Volt Rating (Un)
120 V
AC or DC
AC
Nominal Discharge Current (In) (8/20)
50kA
System Configuration
TT. TNS. TNC. IT
Lightning Impulse Current (10/350) (LIMP)
50 kA
Following Current (Ifi)
50 kA
Number of Poles
1-Pole
Torque Rating
35.403 lb-in
Max. Back-Up Fuse
500 A gG
Housing Material
PC+GF; V-0
Uc (L-N)
150 V
Up at In (L-N)
≤2.0 kV
