KYOCERA Grooving Insert: GDM1516PF PR1535, Solid Carbide Qty 10 8842584

Kyocera
1 Lot of 10 Inserts

MSRP: $100.00

• Insert Style GDM
• Insert Size Code 1516
• Insert Size 1516
• Insert Material Solid Carbide
• Manufacturer Grade PR1535
• Cutting Width (Decimal Inch) 0.0591
• Cutting Width (mm) 1.50
• Insert Holding Method Clamp
• Cutting Height (mm) 3.70
• Insert Hand Neutral
• Cutting Height (Decimal Inch) 0.1457
• Corner Radius (mm) 0.03
• Corner Radius (Decimal Inch) 0.0011
• Rake Positive
• Multi-use Tool Yes
• Cutting Tool Application Cut-Off
• Series GD
• Coating Process PVD
• Rake Angle 2.50
• Overall Length (Decimal Inch) 0.6299
• Overall Length (mm) 16.00
• Primary Workpiece Material Superalloy
• Primary Workpiece Material Code S
• Secondary Workpiece Material Stainless Steel
• Secondary Workpiece Material Code M
• Ansi Code GDM1516N003PFPR1535
• Iso Code GDM1516N003PF
• Standards ISO; ANSI
• Manufacturers Catalog Number GDM1516N-003PF
• Insert Thickness (Decimal Inch) 0.0472
• Chip Breaker PF
• Coating/Finish MEGACOAT NANO
• Insert Thickness 1.20

These items are new and in great condition. SOLD AS IS.

Please review photos, comes as shown.
