KYOCERA DNGA433T00825 PT600M Ceramic Turning Insert Qty 10 TCV02012

Kyocera
1 Lot of 10 Inserts

MSRP: $120.00

• Insert Size Code 433
• Insert Shape Code D
• Insert Shape Diamond
• Clearance Code N
• Tolerance Code G
• Hole/Chipbreaker A
• Manufacturer's Grade PT600M
• Inscribed Circle (Decimal Inch) 0.5000
• Inscribed Circle (mm) 12.70
• Insert Material Ceramic
• Coated Coated
• Corner Radius (Inch) 3/64
• Corner Radius (Decimal Inch) 0.0469; 0.0469 in; 1.1906 mm; 3/64 in
• Coating Process PVD
• Number Of Cutting Edges 4
• Primary Workpiece Material Code H
• Secondary Workpiece Material Code K
• Ansi Code DNGA433T00825PT600M
• Iso Code DNGA50412T02025
• Standards ANSI; ISO
• Hole Diameter (Decimal Inch) 0.2030
• ISO Number DNGA50412T02025
• Rake Negative
• Relief Angle 0?
• Manufacturers Catalog Number DNGA433T00825 PT600M
• Primary Workpiece Material H
• Secondary Workpiece Material Cast Iron
• Cutting Direction Neutral
• Insert Hand Neutral
• Thickness (mm) 4.76
• Thickness (Decimal Inch) 0.1875
• Shape Diamond
• Coating Al2O3/TiC (Megacoat)
• Series ISOI
• Insert Holding Method Pin & Clamp

These items are new and still sealed in the original package. SOLD AS IS.

Please review photos, comes as shown.
