KENNAMETAL Spiral Point Tap: UNF, 2 Flutes, Plug, 3B Qty 3 5479698

Kennametal
1 Lot of 3 Spiral Point Tap

MSRP: $60.00

• Thread Size (Inch) #10-32
• Thread Standard UNF
• Chamfer Plug
• Material High-Speed Steel-E
• Coating/Finish Oxide
• Thread Direction Right Hand
• Coolant Through No
• Class Of Fit 3B
• Number Of Flutes 2
• Oversize No
• Interrupted Thread No
• Threads per Inch 32
• Thread Pitch (Decimal Inch) 0.0313
• Material Grade KSP39
• Thread Length (Decimal Inch) 0.4800
• Thread Length (Inch) 31/64
• Thread Length (mm) 12.19 mm
• Overall Length (Decimal Inch) 2.7600
• Overall Length (mm) 70
• Cnc Shank Yes
• Shank Diameter (mm) 6
• Shank Diameter (Decimal Inch) 0.2362
• Application Through-Hole Threading
• Neck Length (mm) 12.96
• Neck Length (Decimal Inch) 0.5100
• Tapping Depth (mm) 25.15
• Tapping Depth (Decimal Inch) 0.9900
• Square Length (Inch) 5/16
• Square Length (Decimal Inch) 0.3100
• Square Size (Decimal Inch) 0.1930
• Square Size (mm) 4.90
• Material Application Stainless Steel; Cast Iron; Steel
• Series T820
• Style Spiral Point
• UNSPSC Code 23241600

These items appear to be new and in good condition. SOLD AS IS.

Please review photos, comes as shown.
