KENNAMETAL Milling Insert: HNPJ0905ANERLM KC522M, Solid Carbide Qty 5 7064757

Kennametal
1 Lot of 5 Inserts

MSRP: $100.00

• Insert Style HNPJ
• Insert Size 5
• Insert Material Solid Carbide
• Insert Shape Hexagon
• Inscribed Circle (Inch) 5/8
• Manufacturer Grade KC522M
• Corner Radius (Decimal Inch) 0.0470
• Number Of Cutting Edges 12
• Thickness (Decimal Inch - 4 Decimals) 0.2250
• Coating/Finish AlTiN
• Relief Angle 0.00
• Maximum Depth of Cut (Decimal Inch) 0.1770
• Insert Size Code 535
• Material Grade C1
• Width (Inch) 5/8
• Length (Inch) 5/8
• Inscribed Circle (Decimal Inch) 0.6250
• Thickness Range (Decimal Inch) 0.2200 to 0.2350
• Corner Radius (Inch) 3/64
• Inscribed Circle Range (Decimal Inch) 0.6000 to 0.7000
• Length Range (Decimal Inch) 0.6000 to 0.6500
• Insert Hand Right Hand
• Series HNPJ
• Coating Process PVD
• Rake Negative
• Primary Workpiece Material Stainless Steel; Cast Iron; Superalloys & Titanium; Steel
• Primary Workpiece Material Code P; S; K; M
• Ansi Code HNPJ535ANERLM
• Iso Code HNPJ0905ANERLM
• Standards ISO; ANSI
• Cutting Edge Style Honed
• Manufacturers Catalog Number HNPJ0905ANERLM
• Cutter Series Compatibility Dodeka
• Chip Breaker LM
• Material Application Stainless Steel; Cast Iron; Superalloys & Titanium; Steel
• UNSPSC Code 23291601
• Insert Holding Method Screw
• Coating Classification PVD
• Single or Double Sided Insert Double
• Included Angle Degree 120
• Width (Decimal Inch - 4 Decimals) 0.6250
• Multi-Use Tool Yes
• Length (Decimal Inch - 4 Decimals) 0.6250
• System Of Measurement Decimal Inch

These items appear to be new and in good condition. SOLD AS IS.

Please review photos, comes as shown.

Fast shipping, straight from our warehouse in sunny Florida!
