Jergens
Single Acting Cylinder

MSRP: $120

• Action Type Single-Acting
• Operating Stroke Length (Inch) 1
• Operating Stroke Length (Decimal Inch) 1.0000
• Operating Volume (Cu. In.) 1.22
• Operation Type Air/Oil
• Maximum Operating Pressure (psi) 3000.00
• Minimum Operating Pressure (psi) 25.00
• Maximum Output Force (Lb.) 9300
• Base To Shaft End (Inch) 2-5/8
• Mounting Type Bracket
• Outside Diameter (Inch) 1-47/64
• Projection Diameter (Inch) 1/2
• End Port Size 3/8-16
• End Port Thread Depth (Inch) 3/4
• Return Port Size 9/16-18
• Body Length (Inch) 2-3/8
• Shaft Diameter 1.5000 in
• Effective Piston Area (Sq. In.) 1.22
• UNSPSC Code 31162907

*Open package for inspection & photos only*

Please review photos, comes as shown.

Fast shipping, straight from our warehouse in sunny Florida!
