ISCAR Replaceable Drill Tip: IDI0941SG IC908 Qty 2 5505317

Iscar
1 Lot of 2 Replaceable Drill Tips

MSRP: $200.00

• Cutting Diameter (Decimal Inch) 0.9410
• Cutting Diameter (mm) 24.00
• Tip Material Solid Carbide
• Manufacturer Grade IC908
• Material Grade Submicron
• Cutting Direction Right Hand
• Series IDI-SG
• Coating Process PVD
• Insert Geometry SG
• Insert Seat Size 23
• Functional Length (Decimal Inch) 0.2384
• Primary Workpiece Material Hard Material; Stainless Steel; Cast Iron; Superalloys & Titanium; Steel
• Primary Workpiece Material Code P; S; H; K; M
• Standards ISO 13399
• Height (Decimal Inch) 0.409
• Height (mm) 10.00
• Overall Length/Projection (Decimal Inch) 0.4098
• Web Thinning Web Thinned
• Drill Point Angle 140
• Flute Type Helical
• Insert Holding Method Clamp
• ISO Number IDI 239-SG
• Coolant Through No
• Flute Length (mm) 6.00
• Point Type Standard
• Spiral Type Regular Spiral
• Style IDI-SG
• UNSPSC Code 23242105
• Applications Drilling; Hole Making
• Coating/Finish TiAlN
• Included Angle Degree 140
• Number Of Flutes 2

These items are new and in the original sealed package. SOLD AS IS.

Please review photos, comes as shown.
