Iscar Carbide Milling Inserts XNMU 130608PNN-MM IC330 QTY 10 Pcs 5607640

Iscar
Carbide Milling Inserts

MSRP: $170

• Insert Style XNMU
• Insert Size 13
• Insert Material Solid Carbide
• Insert Shape Square
• Manufacturer Grade IC330
• Corner Radius (Decimal Inch) 0.0315
• Corner Radius (mm) 0.79
• Number Of Cutting Edges 8
• Thickness (Decimal Inch - 4 Decimals) 0.3350
• Coating/Finish TiCN; TiN
• Relief Angle 0.00
• Maximum Depth of Cut (Decimal Inch) 0.4803
• Insert Size Code 130608
• Inscribed Circle (Decimal Inch) 0.5120
• Thickness Range (Decimal Inch) 0.2500 to 0.3500
• Corner Radius (Inch) 1/32
• Inscribed Circle Range (Decimal Inch) 0.5100 to 0.6000
• Length Range (Decimal Inch) 0.5000 to 0.6000
• Insert Hand Neutral
• Series HELISLOT
• Coating Process PVD
• Cutting Edge Effective Length (Decimal Inch) 0.4803
• Rake Negative
• Primary Workpiece Material Stainless Steel; Superalloys & Titanium; Steel
• Primary Workpiece Material Code P; S; M
• Secondary Workpiece Material Code S
• Ansi Code XNMU 130608PNN-MM IC330
• Iso Code XNMU 130608PNN-MM
• Standards ISO 13399; ANSI
• Cutting Edge Style T-Land
• Manufacturers Catalog Number XNMU 130608PNN-MM IC330
• Cutter Series Compatibility FDN-XN13; ETS-XN13; SM-XN13; SDN-XN13
• Chip Breaker MM
• Material Application Stainless Steel; Superalloys & Titanium; Steel
• UNSPSC Code 23291601
• Insert Holding Method Screw
• Coating Classification PVD
• Single or Double Sided Insert Double
• Included Angle Degree 90
• Width (Decimal Inch - 4 Decimals) 0.5120
• Width (Mm - 2 Decimals) 13.00
• Multi-Use Tool Yes
• Length (Decimal Inch - 4 Decimals) 0.5118
• System Of Measurement Decimal Inch

*Open package for inspection & photos only*

Please review photos, comes as shown.
