HERTEL WNMG 432-L12 HC1250T Carbide Turning Inserts qty 10 1002249

HERTEL

 WNMG 432-L12 HC1250T Carbide Turning Inserts qty 10 1002249
MSRP: $168

• Insert Style WNMG
• Insert Shape Code W
• Insert Size Code 432
• Insert Shape Trigon
• Coating/Finish Coated
• Corner Radius (Inch) 1/32
• Corner Radius (Decimal Inch) 0.0300
• Insert Material Solid Carbide
• Hole Diameter (Mm) ( - 0 Decimals) 5.16
• Hole Diameter (Decimal Inch) 0.2000
• Maximum Depth of Cut (mm) 5.00
• Maximum Depth of Cut (Decimal Inch) 0.2000
• Inscribed Circle (Inch) 1/2
• Inscribed Circle (Decimal Inch) 0.5000
• Insert Holding Method Pin; Clamp
• Insert Hand Neutral
• Insert Thickness (Inch) 3/16
• Insert Thickness (Decimal Inch) 0.1900
• Clearance Code N
• Tolerance Code M
• Manufacturer Grade HC1250T
• Included Angle 80.0
• Relief Angle 0
• Coating Process CVD
• Length Range (Decimal Inch) 0.5000 - 0.6000
• Rake Negative
• Insert Length (Decimal Inch) 0.5000
• Insert Length (mm) 12.70
• Primary Workpiece Material P
• Secondary Workpiece Material M
• Iso Code WNMG 080408-L12
• Manufacturers Catalog Number WNMG432
• Cutting Direction Neutral
• Material Grade HC1250T
• Single or Multi Tipped Multi Tipped
• Chip Breaker G
• Rake Angle 0

 Please review photos, comes as shown.
