Harvey Tool Corner Radius End Mill 3/16" Dia 9/16" LOC 7FL 882312-C6

Harvey Tool
Corner Radius End Mill

MSRP: $135

• Mill Diameter (Inch): 3/16 Mill Diameter (Decimal Inch): 0.1875
• Number Of Flutes: 7 Length of Cut (Inch): 9/16
• Single Or Double End: Single End Mill Material: Solid Carbide
• Chipbreaker: No Coating/Finish: AlTiN
• Overall Length (Inch): 2-1/2 Centercutting: No
• Flute Direction: Right Hand Corner Radius (Decimal Inch): 0.0150
• Variable Index: No Helix Angle: 20.00
• Cutting Direction: Right Hand Coolant Through: No
• Pitch: Close Overall Length (Decimal Inch): 2.5000
• End Type: Corner Radius Length Of Cut (Decimal Inch - 4 Decimals): 0.5620
• Length Type: Regular Flute Type: Spiral
• Extended Reach: No Shank Type: Straight-Cylindrical
• Material Removal Type: Roughing & Finishing Shank Diameter (Decimal Inch): 0.2500
• Shank Diameter (Inch): 1/4 Corner Radius Tolerance: 0.0010 to -0.0010 in
• Mill Diameter Tolerance: 0.0000/-0.0020 in Shank Diameter Tolerance: h6
• Overall Length Tolerance: 0.0100/-0.0000 in Primary Workpiece Material: Hard Material; Stainless Steel; Cast Iron; Steel
• UNSPSC Code: 27112803 Primary Workpiece Material Code: P; H; K; M
• Series: Material Specific End Mills; End Mills for Hardened Steels - Corner Radius - For Steels 45-68 Rc Material Application: Stainless Steel; Cast Iron; Hard Alloy; Steel
• Coating Classification: PVD For Use With.: High Precision Toolholders

(New in the box. Taken out for inspection and photos.

Outside packaging may be slightly damaged, scuffed or dirty.

Items inside are fine. Comes with instructions. NO warranty is included).

Please review photos, comes as shown.
