GUHRING Micro Drill Bit: 2.60 mm Dia Solid Carbide 9064010026000

GUHRING Micro Drill Bit: 2.60 mm Dia Solid Carbide 9064010026000
MSRP: $100

• Drill Bit Size (mm) 2.60
• Drill Bit Size (Decimal Inch) 0.1024
• Tool Material Solid Carbide
• Flute Length (mm) 23.40
• Coating/Finish TiAlN
• Coolant Through No
• Drill Point Angle 140
• Cutting Direction Right Hand
• Maximum Drilling Depth (mm) 20.20
• Series 6401; 6400
• Overall Length (mm) 67.00
• Flute Type Spiral
• Shank Type Straight-Cylindrical
• Point Type Faceted
• Web Thinning Web-Thinned
• Drill Bit Diameter Tolerance m7
• Primary Workpiece Material Stainless Steel; Cast Iron; Steel
• Primary Workpiece Material Code P; K; M
• Secondary Workpiece Material Aluminum; Titanium Alloy
• Secondary Workpiece Material Code S; N
• Shank Diameter (mm) 4.00
• Flute By Diameter Ratio 7xD
• Material Grade K40
• Spiral Type Regular
• UNSPSC Code 23241600

(Description).

Please review photos, comes as shown.
