Operation Type Hydraulic
Action Type Single-Acting
Swing Direction Right Hand
Clamping Force (Lb.) 4000.00
Clamping Force (kg) 1814.37
Operating Volume (Cu. In.) 1.22 (Clamp)
Port Size SAE #4
Total Stroke Distance (Decimal Inch) 1.0700
Vertical Stroke Distance (Decimal Inch) 0.4500
Mounting Type Threaded Body
Rod Diameter (Decimal Inch) 1.2600
Effective Clamping Area (Sq. In.) 1.10
Maximum Operating Pressure (bar) 344.74
Maximum Operating Pressure (psi) 5000.00
Body Length (Decimal Inch) 4.0900
Body Thread Size 2-1/2 - 16
