GUHRING Jobber Length Drill Bit: 4.00 mm (0.1575) Dia, 150º 9006090040000

GuhringJobber Length Drill Bit

MSRP: $60.00

• Drill Bit Size (mm) 4.00
• Drill Bit Size (Decimal Inch) 0.1575
• Drill Bit Material Solid Carbide
• Drill Point Angle (Degrees) 150
• Coating/Finish TiN
• Flute Type Regular Spiral
• Cutting Direction Right Hand
• Point Type Standard
• Primary Workpiece Material Aluminum & Non-Ferrous; Cast Iron; Steel
• Specification Number DIN 6539
• Coolant Through No
• Flute Length (Decimal Inch) 1.1810
• Flute Length (mm) 30.00
• Number of Flutes 3
• Shank Diameter (Decimal Inch) 0.1575
• Overall Length (mm) 54.99
• Overall Length (Decimal Inch) 2.1650
• Spiral Type Regular
• Series 609
• Tool Application Self-Centering
• Flute By Diameter Ratio 5xD
• Maximum Drilling Depth (Decimal Inch) 0.9500
• Maximum Drilling Depth (mm) 24.00
• Shank Length (mm) 25
• Drill Bit Diameter Tolerance -0.012 to 0.000 mm
• Web Thinning Web-Thinned
• Web Configuration Tapered
• Shank Type Straight
• Standards DIN 6539
• Drill Bit Grade High Performance
• Drill Bit Size Range (Decimal Inch) 0.1500 - 0.2000
• Drill Bit Size Range (mm) 4.00 - 5.00
• Material Grade Submicron
• Specification Designation DIN

This item appears to be new and in good condition. SOLD AS IS.

Please review photos, comes as shown.
